Aruba 2530 switch with 8 ports and 2 dual personality ports / J9783A

11.500,00 EGP

SKU: J9783A Categories: Network, Switches

The Aruba 2530-8 Switch (J9783A) is an enterprise-grade Layer 2 managed Fast Ethernet switch engineered for secure, reliable branch and small business edge connectivity. Featuring 8 10/100 ports and 2 dual-personality Gigabit uplinks, it delivers 5.6 Gbps switching capacity, fanless silent operation, ACL security, traffic prioritization, and centralized management via Aruba AirWave or ClearPass.

20 People watching this product now!

Get More Info

Datasheet

Compare

Pick up from the Our Store

To pick up today from 9 am to 6 pm

Free

Courier, UBER, DiDi delivery

Our courier will deliver to the specified address

30-45 Minutes

with Fees

DHL Courier delivery

DHL courier will deliver to the specified address

1-2 Days

with Fees

Payment Methods:

Description

Aruba 2530-8 Layer 2 Managed 8-Port Fast Ethernet Switch (Part Number: J9783A) is a cost-effective, enterprise-grade access switch engineered for small businesses, branch offices, and commercial workspaces requiring dependable edge connectivity. It features 8 RJ-45 10/100BASE-TX Fast Ethernet ports alongside 2 dual-personality Gigabit uplink ports (supporting either 10/100/1000BASE-T RJ-45 or Gigabit SFP transceiver slots). The switch delivers a non-blocking switching throughput of 5.6 Gbps and a forwarding rate of up to 4.1 Mpps to ensure fluid network operations.

The 2530-8 provides full Layer 2 management capabilities, including 802.1Q VLAN support, IEEE 802.1p traffic prioritization (QoS), Access Control Lists (ACLs), and port security to protect sensitive network resources. Designed with a fanless thermal architecture, it operates completely silently, making it ideal for acoustic-sensitive deployments such as desktop offices, conference rooms, and reception counters. It can be managed centrally via Aruba AirWave Network Management or integrated into secure policy environments using Aruba ClearPass Policy Manager.

Technical Specifications

Component / Parameter	Technical Specification
Product Line	Aruba 2530 Switch Series
Model / SKU	Aruba 2530-8 Switch (Part Number: J9783A)
Switching Architecture	Fully Managed Layer 2 Fast Ethernet Access Switch
Fast Ethernet Ports	8× RJ-45 autosensing 10/100BASE-TX ports (IEEE 802.3u)
Gigabit Uplink Ports	2× Dual-personality Gigabit ports (10/100/1000BASE-T or 100/1000 SFP slots)
Management Console	1× RJ-45 serial console port, 1× Micro-USB console port
Switching Capacity	5.6 Gbps
Throughput (Forwarding Rate)	Up to 4.1 Mpps (64-byte packets)
MAC Address Table Size	16,000 entries
Processor & Memory	ARM9E @ 800 MHz, 128 MB flash, 256 MB DDR3 DIMM, packet buffer size: 1.5 MB
Latency	100 Mb Latency: < 1.3 μs; 1000 Mb Latency: < 1.3 μs (FIFO 64-byte packets)
Management Protocols	Aruba AirWave, ClearPass, SNMP v1/v2c/v3, Web GUI, Command Line Interface (CLI)

Switch Port, Stacking & Power Specifications

Parameter / Feature	Specification / Rating
Port Density	8 Fast Ethernet copper ports + 2 Dual-Personality Gigabit combo uplinks
PoE Capability	Non-PoE model (data-only switching)
Acoustic Noise	0 dB (Fanless silent operation)
Input Voltage Rating	100 – 240 V AC nominal, 50/60 Hz (external power adapter included)
Maximum Power Draw	7.2 W (Idle: 4.5 W)
Energy Efficiency	IEEE 802.3az Energy Efficient Ethernet compliance

Mechanical & Environmental Specifications

Parameter / Feature	Specification / Rating
Dimensions (W × D × H)	254 mm × 159.5 mm × 44.5 mm (10.0 in × 6.28 in × 1.75 in, 1U height)
Unit Weight	0.82 kg (1.81 lbs)
Mounting Options	Desktop, wall, and under-table mounting with included hardware
Operating Temperature Range	0°C to +45°C (+32°F to +113°F)
Operating Humidity Range	15% to 95% relative humidity at 40°C (non-condensing)
Mean Time Between Failures (MTBF)	504,000 hours (57.5 years)
Safety & Compliance	UL 60950-1, EN 60950-1, FCC Class A, CE Mark, RoHS compliant

Key Features & Capabilities

Robust Layer 2 Switching: Delivers complete Layer 2 switching capabilities including IEEE 802.1Q VLAN tagging and link aggregation.
Dual-Personality Uplinks: Flexible uplink design supports either copper Gigabit Ethernet or fiber SFP transceivers for backbone uplinks.
Fanless Silent Operation: Zero-noise acoustic profile makes the switch ideal for deployment in open offices and shared work environments.
Advanced Security Controls: Incorporates IEEE 802.1X port authentication, RADIUS/TACACS+, and MAC address lockdown.
Traffic Prioritization & QoS: Features IEEE 802.1p traffic prioritization with 8 priority queues for latency-sensitive voice and video streams.
Centralized Network Management: Seamlessly managed via command-line interface (CLI), web browser, Aruba AirWave, or Aruba ClearPass.

Recommended Applications

The Aruba 2530-8 Layer 2 Managed 8-Port Fast Ethernet Switch is engineered for commercial edge deployments, including:

Small branch offices requiring managed wired connectivity for workstations and printers.
Retail POS counters and hospitality front-desks needing silent, reliable Ethernet switching.
Classrooms and training labs where fanless acoustic silence is essential.
Industrial control panels and commercial kiosks utilizing Fast Ethernet automation sensors.
Space-constrained wall-mount utility enclosures requiring a compact 10-inch form factor.

Installation & Operating Environment

The Aruba 2530-8 switch features an ultra-compact, fanless steel chassis measuring 254 mm × 159.5 mm × 44.5 mm and weighing just 0.82 kg. It includes mounting brackets for solid wall, under-table, and desktop placement. It operates reliably in ambient temperatures from 0°C to +45°C with 15% to 95% non-condensing relative humidity. Powered via an included energy-efficient 100-240V AC external power adapter drawing a maximum of only 7.2W, it delivers continuous enterprise-grade reliability with minimal electrical overhead.
