Description
Grandstream GWN Series GWN7605 Wave-2 2×2:2 Wi-Fi Access Point (Model: GWN7605) is a Enterprise Wave-2 Wi-Fi Access Point engineered for retail outlets, multi-floor corporate offices, hospitality venues, and medical clinics. Delivers 1.267 Gbps aggregate dual-band wireless throughput (867 Mbps on 5GHz, 400 Mbps on 2.4GHz), dual-band 2×2:2 MU-MIMO with beamforming, up to 165 meters coverage range, and 100+ concurrent client device support.
Featuring dual auto-sensing Gigabit Ethernet ports with integrated PoE/PoE+ (802.3af/802.3at), it incorporates an embedded controller capable of managing up to 50 local GWN APs without external hardware. It integrates seamlessly with GWN.Cloud and GWN Manager, featuring fanless heat dissipation and enterprise QoS.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | GWN Series |
| Model / SKU | GWN7605 |
| Capacity / Scale | 100+ Concurrent Wi-Fi Clients; Up to 16 SSIDs per Radio; 1.267 Gbps Aggregate Throughput |
| Network / Telephony Interfaces | 2x Auto-sensing 10/100/1000 Base-T RJ45 Ethernet Ports (PoE/PoE+ input on Port 1) |
| Packet / Voice Processing | IEEE 802.11a/b/g/n/ac Wave-2; 2×2:2 MU-MIMO (5GHz) & 2×2:2 MIMO (2.4GHz); Beamforming; Advanced QoS |
| Expansion & Peripheral Ports | 1x Factory Reset Pinhole, 1x Kensington Lock Slot |
| Operating System / Management | Embedded Controller (up to 50 APs), GWN.Cloud, GWN Manager (on-premise server software), Web UI |
| Power Supply Specifications | PoE 802.3af / 802.3at; Maximum Power Consumption 10.16W (PoE injector not included) |
| Maximum Power Consumption | 10.16W |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Physical Dimensions (L × W × H) | 193.7 × 193.7 × 40 mm |
| Unit Weight | 365 g (0.365 kg) |
| Chassis & Display | Tricolor LED status indicator; Internal antenna array (2 dual-band antennas, 3dBi gain) |
| Heat Dissipation / Cooling | Fanless natural heat dissipation (noise-free operation) |
| Operating Temperature Range | 0°C to 40°C (32°F to 104°F) |
| Operating Relative Humidity | 10% to 90% (Non-condensing) |
| Mounting Capabilities | Indoor wall mount or ceiling mount (kits included) |
Key Features & Capabilities
- Wave-2 2×2:2 Performance: Delivers 1.267 Gbps aggregate wireless throughput with dual-band 2×2:2 MU-MIMO beamforming.
- Dual Gigabit Interfaces: Equipped with 2 auto-sensing Gigabit ports with integrated PoE/PoE+ input support.
- 165-Meter Coverage Radius: Advanced antenna array delivers stable wireless coverage across an extended 165-meter range.
- Silent Fanless Design: Passive natural convection cooling guarantees silent operation in noise-sensitive business spaces.
- Anti-Hacking Security: Protected by anti-hacking secure boot, critical data/control lockdown via digital signatures, and unique QR code credentials.
- Embedded Controller: Built-in controller provisions and manages up to 50 local GWN series APs without dedicated controller hardware.
Recommended Applications
The Grandstream GWN Series GWN7605 Wave-2 2×2:2 Wi-Fi Access Point is designed for enterprise and commercial deployment scenarios, including:
- Commercial retail branch stores requiring reliable guest Wi-Fi and POS connectivity
- Medium-density corporate offices requiring robust wireless voice and data access
- Hospitality venues providing seamless guest Wi-Fi coverage across guest rooms
- Educational classrooms and tutoring centers supporting concurrent student tablets
- Medical clinics requiring secure, segmented medical staff and patient wireless networks
Installation & Operating Environment
The Grandstream GWN Series GWN7605 Wave-2 2×2:2 Wi-Fi Access Point features a Indoor wall mount or ceiling mount enclosure measuring 193.7 × 193.7 × 40 mm and weighing 365 g (0.365 kg). It operates across an environmental temperature range of 0°C to 40°C (32°F to 104°F) and relative humidity of 10% to 90% (Non-condensing). Powered via PoE 802.3af / 802.3at; Maximum Power Consumption 10.16W (PoE injector not included), it ensures dependable continuous operation and structured integration into commercial networking racks and office work environments.
