Description
Grandstream GWN Series GWN7615 Wave-2 3×3:3 Wi-Fi Access Point (Model: GWN7615) is a High-Density Enterprise Wave-2 Wi-Fi Access Point engineered for multi-floor office buildings, commercial convention spaces, educational campuses, and hotels. Delivers up to 1.75 Gbps aggregate dual-band throughput (1.3 Gbps on 5GHz, 450 Mbps on 2.4GHz), 3×3:3 MU-MIMO technology, up to 175 meters coverage range, and reliable support for 200+ concurrent Wi-Fi client devices.
Equipped with dual auto-sensing Gigabit ports with PoE/PoE+ (802.3af/802.3at), it incorporates an embedded controller managing up to 50 local GWN APs. Supported by GWN.Cloud and GWN Manager, it features advanced QoS for low-latency voice-over-Wi-Fi, fanless cooling, and anti-hacking digital security.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | GWN Series |
| Model / SKU | GWN7615 |
| Capacity / Scale | 200+ Concurrent Wi-Fi Clients; Up to 16 SSIDs per Radio; 1.75 Gbps Aggregate Throughput |
| Network / Telephony Interfaces | 2x Auto-sensing 10/100/1000 Base-T RJ45 Ethernet Ports (PoE/PoE+ input on Port 1) |
| Packet / Voice Processing | IEEE 802.11a/b/g/n/ac Wave-2; 3×3:3 MU-MIMO (5GHz) & 3×3:3 MIMO (2.4GHz); Beamforming; Voice QoS |
| Expansion & Peripheral Ports | 1x Factory Reset Pinhole, 1x Kensington Lock Slot |
| Operating System / Management | Embedded Controller (up to 50 APs), GWN.Cloud, GWN Manager (on-premise server software), Web UI |
| Power Supply Specifications | PoE 802.3af / 802.3at; Maximum Power Consumption 12.5W (PoE injector not included) |
| Maximum Power Consumption | 12.5W |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Physical Dimensions (L × W × H) | 205.3 × 205.3 × 45.9 mm |
| Unit Weight | 500 g (0.5 kg) |
| Chassis & Display | Tricolor LED status indicator; 3 dual-band internal antennas (up to 3dBi gain) |
| Heat Dissipation / Cooling | Fanless natural heat dissipation (noise-free operation) |
| Operating Temperature Range | 0°C to 40°C (32°F to 104°F) |
| Operating Relative Humidity | 10% to 90% (Non-condensing) |
| Mounting Capabilities | Indoor wall mount or ceiling mount (kits included) |
Key Features & Capabilities
- 3×3:3 MU-MIMO Capacity: Delivers 1.75 Gbps aggregate throughput with 3×3:3 MU-MIMO on 5GHz for dense client environments.
- High Client Density: Supports 200+ simultaneous client devices without degradation in wireless throughput or stability.
- Extended 175m Range: Engineered internal antenna array delivers long-range wireless coverage up to 175 meters.
- Acoustic & Thermal Design: Fanless convection cooling architecture guarantees silent ceiling-mounted performance.
- Hardware Security Shield: Anti-hacking secure boot and critical data locking via digital signatures safeguard network integrity.
- Autonomous Management: Embedded controller manages up to 50 local APs; seamlessly managed via GWN.Cloud and GWN Manager.
Recommended Applications
The Grandstream GWN Series GWN7615 Wave-2 3×3:3 Wi-Fi Access Point is designed for enterprise and commercial deployment scenarios, including:
- High-density corporate office floors with open collaborative workstations
- Hospitality conference centers and hotel ballrooms hosting large attendee gatherings
- University lecture halls and campus libraries supporting multi-device student access
- Commercial shopping centers and retail complexes with high public visitor traffic
- Enterprise voice-over-Wi-Fi deployments requiring low-latency roaming
Installation & Operating Environment
The Grandstream GWN Series GWN7615 Wave-2 3×3:3 Wi-Fi Access Point features a Indoor wall mount or ceiling mount enclosure measuring 205.3 × 205.3 × 45.9 mm and weighing 500 g (0.5 kg). It operates across an environmental temperature range of 0°C to 40°C (32°F to 104°F) and relative humidity of 10% to 90% (Non-condensing). Powered via PoE 802.3af / 802.3at; Maximum Power Consumption 12.5W (PoE injector not included), it ensures dependable continuous operation and structured integration into commercial networking racks and office work environments.
