Description
Aruba 2930F 8G PoE+ 2SFP+ Layer 3 Managed Compact Switch (Part Number: JL258A) is an enterprise-class compact edge switch engineered for branch offices, retail locations, and distributed enterprise workspaces. It combines 8 autosensing 10/100/1000BASE-T PoE+ ports with 2 high-speed 1G/10G SFP+ optical uplink ports, providing a non-blocking switching throughput of 56 Gbps and a forwarding rate of 41.7 Mpps. Designed with a robust 125W PoE+ power budget, it reliably powers high-performance Wi-Fi 6 access points, smart digital signage, and VoIP telecommunications.
The 2930F 8G PoE+ features a completely fanless design that provides zero acoustic noise, making it suitable for deployment in open offices and public venues. It delivers enterprise-grade Layer 3 routing capabilities, including Access OSPF, RIP, static IP routing, and VSF virtual stacking. It offers zero-touch provisioning and role-based access security through Aruba ClearPass Policy Manager and central visibility via Aruba Central or AirWave.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Aruba 2930F Switch Series |
| Model / SKU | Aruba 2930F 8G PoE+ 2SFP+ Switch (Part Number: JL258A) |
| Switching Architecture | Compact Layer 3 Managed Access Switch |
| Copper Ports | 8× RJ-45 autosensing 10/100/1000BASE-T PoE+ ports (IEEE 802.3at Class 4) |
| Fiber Uplink Ports | 2× 1G/10G SFP+ optical transceiver slots |
| PoE Power Budget | 125 W PoE+ |
| Switching Capacity | 56 Gbps |
| Throughput (Forwarding Rate) | Up to 41.7 Mpps (64-byte packets) |
| Latency | 1000 Mb: < 3.8 μs; 10 Gbps: < 1.5 μs (FIFO 64-byte packets) |
| Acoustic Profile | 0 dB (Fanless silent operation) |
| Routing Protocols | Static IPv4/IPv6, RIPv1/v2, Access OSPF, ECMP |
| Virtual Stacking | Virtual Switching Framework (VSF) stacking up to 8 switches |
Switch Port, Stacking & Power Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Port Density | 8 Gigabit PoE+ copper ports + 2 10GbE SFP+ fiber ports |
| PoE Standards Supported | IEEE 802.3af (PoE Class 3) / IEEE 802.3at (PoE+ Class 4) |
| PoE Budget | 125 W |
| Max Power Consumption | 155 W (at full 125W PoE output) |
| Idle Power Consumption | 19.7 W |
| Input Voltage Rating | 100 – 127 / 200 – 240 V AC internal power supply, 50/60 Hz |
| Energy Efficiency | IEEE 802.3az Energy Efficient Ethernet compliance |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Dimensions (W × D × H) | 254 mm × 254 mm × 43.9 mm (10.0 in × 10.0 in × 1.73 in, 1U compact) |
| Unit Weight | 2.00 kg (4.41 lbs) |
| Mounting Options | Wall, desktop, under-table, or rack-mountable with optional shelf kit |
| Operating Temperature Range | 0°C to +45°C (+32°F to +113°F) |
| Operating Humidity Range | 15% to 95% relative humidity at 40°C (non-condensing) |
| Mean Time Between Failures (MTBF) | 314,900 hours (35.9 years) |
| Security Standards & Hardware | IEEE 802.1X, RADIUS, TACACS+, MACsec ready, TPM hardware security |
Key Features & Capabilities
- High-Speed 10G SFP+ Uplinks: Dual 10GbE SFP+ ports eliminate network aggregation bottlenecks between access closets and core fabrics.
- Compact Fanless Design: Delivers completely silent operation for placement in meeting rooms, retail counters, and open offices.
- 125W PoE+ Power Delivery: Provides ample power to support dense Wi-Fi 6 deployments and motorized PTZ security cameras.
- Enterprise Layer 3 Capabilities: Delivers static IP routing, Access OSPF, and RIP for high-performance localized subnet routing.
- VSF Virtual Stacking: Consolidates multiple switches into a single managed device with automated link aggregation failover.
- Unified ClearPass Policy: Enforces dynamic role-based segmentation and IoT security policies across wired networks.
Recommended Applications
The Aruba 2930F 8G PoE+ 2SFP+ Layer 3 Managed Compact Switch is engineered for space-constrained and acoustic-sensitive environments, including:
- Remote branch offices requiring high-speed 10G fiber uplinks and local PoE+ power.
- Conference rooms, healthcare treatment rooms, and classrooms where silent operation is required.
- Retail checkout counters and smart kiosk installations powering PoE terminals and cameras.
- Industrial automation cabinets and building management hubs requiring 10-inch form factors.
- Hospitality suites providing dedicated wired Gigabit access and in-room Wi-Fi AP backhauls.
Installation & Operating Environment
The Aruba 2930F 8G PoE+ switch features a compact, heavy-gauge steel enclosure measuring 254 mm × 254 mm × 43.9 mm and weighing 2.00 kg. It can be installed on desktops, secured under counters, wall-mounted, or integrated into equipment racks using standard brackets. Operating silently across temperature ranges from 0°C to +45°C and relative humidity levels between 15% and 95%, it houses an integrated internal power supply (100-240V AC) that eliminates bulky external AC adapters while maintaining enterprise reliability.
