Description
Grandstream HA Series HA100 High Availability Controller (Model: HA100) is a Automated Hardware High Availability Controller engineered for mission-critical enterprises, financial institutions, emergency call centers, and government bodies. Connects 2 UCM6510 IP PBXs in an active/standby failover cluster, constantly monitoring system operational status and automatically switching all telecom lines and network connections within 10 to 50 seconds upon failure.
Equipped with dedicated T1/E1/J1 failover ports, analog FXO/FXS trunk relays, and RS485 communication interfaces, it operates with zero human intervention during primary node failures. Housed in a standard 1U rackmount enclosure, its passive fanless cooling ensures silent, dependable operation.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | HA Series |
| Model / SKU | HA100 |
| Capacity / Scale | Supports 2x UCM6510 IP PBXs (Active / Standby Clustering); Automatic failover within 10-50s |
| Network / Telephony Interfaces | 1x Analog FXS Data Port, 1x Analog FXO Data Port, 2x T1/E1/J1 Data Ports, 2x RS485 Ports, 2x USB Ports |
| Packet / Voice Processing | Hardware-driven telecom line relay switching; Zero packet delay; Transparent digital/analog pass-through |
| Expansion & Peripheral Ports | Dual RS485 interfaces for continuous heartbeat health monitoring |
| Operating System / Management | Managed and synchronized directly through connected Grandstream UCM6510 IP PBX web interfaces |
| Power Supply Specifications | External Universal Power Adapter 100-240VAC 50/60Hz, Output 12VDC 1.5A |
| Maximum Power Consumption | 8W |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Physical Dimensions (L × W × H) | 440 × 185 × 44 mm (1U 19-inch rack-mount) |
| Unit Weight | 2150 g (2.15 kg) |
| Chassis & Display | LED status indicators for Power, Status, System Health, FXS, FXO, and T1/E1 lines; 1U metal housing |
| Heat Dissipation / Cooling | Fanless natural heat dissipation (noise-free operation) |
| Operating Temperature Range | 0°C to 45°C (32°F to 113°F) |
| Operating Relative Humidity | 10% to 90% (Non-condensing) |
| Mounting Capabilities | 19" Rack-mount (1U) and Desktop |
Key Features & Capabilities
- Automated Hardware Failover: Automatically switches all telecom trunks and extensions to standby PBX within 10 to 50 seconds.
- Full Trunk Redundancy: Switches analog FXS/FXO ports and digital T1/E1/J1 spans transparently during outages.
- Continuous Heartbeat Tracking: Dual RS485 data links continuously monitor active PBX operational parameters.
- Fanless Convection Cooling: Passive thermal cooling ensures silent, maintenance-free operation inside enterprise server racks.
- Transparent Telecom Passthrough: Preserves existing line configurations, DID mappings, and extension registrations automatically.
- Automated System Sync: Synchronizes PBX configuration databases and CDR call logs seamlessly between clustered nodes.
Recommended Applications
The Grandstream HA Series HA100 High Availability Controller is designed for enterprise and commercial deployment scenarios, including:
- Mission-critical enterprise headquarters requiring 99.999% voice communications uptime
- Emergency dispatch centers and 911 dispatch telephony requiring redundant failover
- Financial institutions and banking trading floors where telephone downtime is unacceptable
- Healthcare hospital communications maintaining continuous lifeline and emergency calling
- Government and municipal telecommunications infrastructure requiring carrier-grade survivability
Installation & Operating Environment
The Grandstream HA Series HA100 High Availability Controller features a 19" Rack-mount (1U) and Desktop enclosure measuring 440 × 185 × 44 mm (1U 19-inch rack-mount) and weighing 2150 g (2.15 kg). It operates across an environmental temperature range of 0°C to 45°C (32°F to 113°F) and relative humidity of 10% to 90% (Non-condensing). Powered via External Universal Power Adapter 100-240VAC 50/60Hz, Output 12VDC 1.5A, it ensures dependable continuous operation and structured integration into commercial networking racks and office work environments.
