Description
Aruba Instant On AP11 (EG) Dual-Band Wi-Fi 5 Indoor Access Point (Part Number: R2W97A) is an affordable, enterprise-grade 802.11ac Wave 2 indoor access point designed for small boutique offices, coffee shops, dental clinics, and home businesses. Operating under the Egypt (EG) regulatory profile, it delivers a maximum real-world aggregate data rate of 1.167 Gbps, powered by 2×2:2 MU-MIMO with up to 867 Mbps on the 5 GHz band and up to 300 Mbps on the 2.4 GHz band. Multi-user MIMO capability ensures multiple wireless clients receive high-speed data simultaneously without channel congestion.
The AP11 (EG) features built-in Smart Mesh technology that allows seamless wireless expansion across physical spaces without needing new Ethernet cables. It includes an integrated Bluetooth Low Energy (BLE) radio for fast smartphone setup and location capabilities. Supporting enterprise-grade WPA2/WPA3 security, customizable guest portals, and automated firmware updates, the AP11 is easily deployed and managed from anywhere via the Aruba Instant On mobile application or web portal.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Aruba Instant On Access Points |
| Model / SKU | Aruba Instant On AP11 (Part Number: R2W97A) |
| Regulatory Domain | Egypt (EG) |
| Wireless Standards | IEEE 802.11ac Wave 2, IEEE 802.11a/b/g/n |
| MIMO Configuration | Dual Radio 2×2:2 MU-MIMO (5 GHz) and 2×2:2 MIMO (2.4 GHz) |
| Maximum Aggregate Speed | 1.167 Gbps (867 Mbps on 5 GHz + 300 Mbps on 2.4 GHz) |
| Recommended Client Capacity | Up to 50 active devices per access point |
| Wired Uplink Port | 1× 10/100/1000BASE-T Gigabit Ethernet RJ-45 (PoE-PD) |
| Integrated Bluetooth Radio | Bluetooth Low Energy (BLE) radio for setup and proximity |
| Mesh Networking | Built-in Smart Mesh technology for wireless expansion |
| Security Protocols | WPA2, WPA3-Personal, WPA3-Enterprise, Enhanced Open (OWE) |
| Management Interface | Aruba Instant On Mobile App (Android/iOS) and Cloud Web Portal |
RF, Antenna & Power Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Antenna Architecture | Integrated downtilt omnidirectional antennas for 2×2 MIMO |
| Peak Antenna Gain | 3.3 dBi in 2.4 GHz, 5.8 dBi in 5 GHz |
| Conducted Transmit Power | +19 dBm in 5 GHz, +19 dBm in 2.4 GHz (per chain) |
| Power over Ethernet (PoE-PD) | IEEE 802.3af (PoE Class 3) |
| Direct DC Power Option | 12 V DC nominal (±5%), circular plug (adapter sold separately) |
| Max Power Consumption | 10.1 W (PoE) / 9.3 W (DC) |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Dimensions (W × D × H) | 152 mm × 152 mm × 34 mm (5.98 in × 5.98 in × 1.34 in) |
| Unit Weight | 193 g (0.43 lbs) |
| Mounting Compatibility | Ceiling tile rail mount and solid flat surface mount bracket included |
| Operating Temperature Range | 0°C to +40°C (+32°F to +104°F) |
| Operating Humidity Range | 5% to 93% relative humidity (non-condensing) |
| Mean Time Between Failures (MTBF) | 1,470,000 hours (168 years) at +25°C |
| Environmental Certifications | UL 2043 plenum rating for air-handling spaces |
Key Features & Capabilities
- High-Speed 802.11ac Wave 2: 2×2:2 MU-MIMO provides reliable wireless data rates up to 1.167 Gbps for multiple mobile devices.
- Smart Mesh Capability: Expands Wi-Fi reach into difficult-to-wire areas without running structural network cables.
- Zero-Touch Mobile Setup: Connect and configure your network in minutes using the intuitive Aruba Instant On mobile application.
- Custom Guest Access Portal: Built-in captive portal with customizable branding, terms of service, and guest isolation.
- Latest WPA3 Security: Advanced wireless encryption safeguards enterprise communications and sensitive payment data.
- UL 2043 Plenum Certified: Safe and compliant for ceiling tile installations in commercial air-handling environments.
Recommended Applications
The Aruba Instant On AP11 (EG) Dual-Band Wi-Fi 5 Indoor Access Point is engineered for boutique commercial spaces, including:
- Professional boutique offices (consultants, attorneys, accountants) connecting laptops and smart phones.
- Coffee shops, bakeries, and casual dining venues providing guest Wi-Fi and mobile payments.
- Medical clinics, dental offices, and wellness spas providing segregated patient and administrative networks.
- Retail storefronts supporting wireless point-of-sale tablets and handheld inventory devices.
- Ceiling plenum drop-tile spaces requiring UL 2043 certified fire-safe equipment.
Installation & Operating Environment
The Aruba Instant On AP11 (EG) access point features an ultra-compact, discreet white enclosure measuring 152 mm × 152 mm × 34 mm and weighing only 193 g. It comes packaged with a dual-mount clip that mounts cleanly onto 9/16-inch or 15/16-inch suspended ceiling rails or directly to solid wall surfaces. Engineered for continuous operation from 0°C to +40°C and 5% to 93% non-condensing relative humidity, it is powered via standard 802.3af PoE or an optional external 12V DC power adapter, providing dependable commercial wireless coverage.
