Huawei eKIT S310S-24T4J Smart Managed Switch (Model: S220S-24T4J) is a high-density 24-port Gigabit switch engineered with four 2.5-Gigabit SFP optical uplinks to provide high-speed, congestion-free network distribution for enterprise workgroups. It features 24 fixed 10/100/1000BASE-T Gigabit Ethernet ports and 4 dedicated 2.5GE SFP optical slots, achieving a switching bandwidth of 68 Gbps and a packet forwarding rate of 51 Mpps.
Housed in a standard 1U 19-inch rackmount metal chassis with internal AC power and fanless natural heat dissipation, the switch delivers enterprise Layer 2 features including 802.1Q VLANs, Link Aggregation (LACP), STP/RSTP/MSTP, and IGMP Snooping with full cloud management via Huawei eKit.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKIT S310S Series |
| Model / SKU | S220S-24T4J (S310S-24T4J) |
| Downlink Ports | 24 × 10/100/1000BASE-T Gigabit Ethernet Ports |
| Uplink Interfaces | 4 × 2.5GE SFP Dedicated Optical Transceiver Slots |
| Switching Capacity | 68 Gbit/s Wire-Speed Non-Blocking Bandwidth |
| Forwarding Performance | 51 Mpps |
| Layer 2 Capabilities | 802.1Q VLANs, Link Aggregation (LACP), STP/RSTP/MSTP, IGMP Snooping |
| Management Interface | Huawei eKit Cloud Platform, Intuitive Web GUI, SNMP v1/v2c/v3 |
| Form Factor | Standard 1U 19-Inch Rackmount Metal Chassis with Internal Power Supply |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Standard 1U 19-Inch Rackmount Chassis |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Industrial-Grade Steel Housing |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- Quad 2.5G SFP Optical Uplinks: Four 2.5G SFP fiber uplinks connect to core distribution switches without bottlenecks.
- High Port Density: 24 Gigabit Ethernet ports provide 68 Gbps switching capacity and 51 Mpps forwarding rate.
- Fanless Quiet Operation: Passive natural heat dissipation ensures noise-free operation in open office spaces and retail shops.
- Layer 2 Management Suite: Full support for 802.1Q VLANs, LACP port trunking, spanning tree protocols, and IGMP snooping.
- Cloud & App Management: Remote network monitoring, topology visualization, and port management via Huawei eKit App.
- Standard 1U Rack Chassis: Heavy-duty 19-inch metal enclosure includes complete rackmount brackets, screws, and rubber feet.
Recommended Applications
The Huawei eKIT S310S-24T4J Smart Managed Switch is engineered for access and aggregation scenarios across commercial environments:
- High-speed Gigabit switching for 24 employee desktops and peripherals in corporate offices.
- Four 2.5G SFP fiber uplinks connecting to core distribution switches.
- Remote configuration, monitoring, and alerts via the Huawei eKit Mobile App.
- Congestion-free data transmission for local file servers and backup NAS.
- Quiet, dependable Gigabit switching for checkout counters and office PCs.
Installation & Operating Environment
The Huawei eKIT S310S-24T4J Smart Managed Switch features a standard 1U 19-inch metal chassis supplied with mounting brackets and rubber feet for seamless installation in commercial server racks or on desktops. Powered by an internal universal AC power supply, it maintains efficient natural heat dissipation for continuous, quiet operation in enterprise facilities.
