Huawei eKitEngine S110-8T2ST Unmanaged Gigabit Switch (Model: S110-8T2ST) is an unmanaged desktop and rack-compatible commercial switch engineered to provide silent, reliable Layer 2 Ethernet connectivity for small-to-medium business workspaces. It features 8 fixed 10/100/1000BASE-T auto-sensing RJ45 Ethernet ports, 1 dedicated 1000BASE-X SFP optical transceiver slot, and 1 Gigabit RJ45 uplink port, delivering 20 Gbps total switching bandwidth and 14.88 Mpps packet forwarding throughput.
Designed for zero-configuration, plug-and-play installation, the switch requires no network management overhead or software commissioning. It is housed in a robust metal enclosure with fanless natural heat dissipation, making it ideal for noise-sensitive environments including executive offices, classrooms, retail shops, and medical clinics.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKitEngine S110 Series |
| Model / SKU | S110-8T2ST |
| Management Type | Unmanaged (Plug-and-Play) |
| Downlink Ports | 8 × 10/100/1000BASE-T Gigabit RJ45 Ports |
| Uplink Interfaces | 1 × GE SFP Optical Port + 1 × 10/100/1000BASE-T RJ45 Port |
| Switching Bandwidth | 20 Gbit/s Wire-Speed Bandwidth |
| Packet Forwarding Rate | 14.88 Mpps |
| MAC Address Table | Up to 8K MAC Address Entries |
| Form Factor | Compact Desktop / Wall-Mount Metal Chassis with Rack Ears |
| Power Supply | Internal Universal AC Power Supply (100V to 240V AC, 50/60Hz) |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Compact Desktop / 1U Rackmount Compatible |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | High-Strength Commercial Metal Housing |
| Power Connector | Standard IEC AC Power Input |
Key Features & Highlights
- Wire-Speed Gigabit Connectivity: 8 Gigabit RJ45 ports provide 20 Gbps switching bandwidth and 14.88 Mpps forwarding throughput for desktop PCs and IP terminals.
- Dedicated SFP Fiber & Copper Uplinks: 1 Gigabit SFP optical slot and 1 RJ45 uplink enable flexible long-reach and copper backhauls.
- Fanless Natural Cooling: Passive thermal engineering delivers noise-free natural heat dissipation, perfect for quiet open-plan offices.
- Plug-and-Play Simplicity: Unmanaged architecture requires zero complex software setup, providing instant connectivity upon boot.
- Internal Universal AC Power: Integrated internal power supply eliminates cumbersome external power bricks and adapters.
- Heavy-Duty Metal Enclosure: Industrial-grade metal housing ensures electromagnetic shielding and durability.
Recommended Applications
The Huawei eKitEngine S110-8T2ST Unmanaged Switch is engineered for access and aggregation scenarios across commercial environments:
- Small business office workgroups connecting up to 8 desktop computers, network printers, and network-attached storage (NAS).
- Retail checkout and POS systems requiring plug-and-play reliability with optical backhaul to the central server room.
- Hospitality guest service areas and reception desks needing silent, fanless operation without disturbing visitors.
- Educational classrooms and computer labs demanding dependable Gigabit distribution without ongoing management overhead.
- Branch office edge distribution providing fiber uplinks back to enterprise core switches.
Installation & Operating Environment
The Huawei eKitEngine S110-8T2ST Unmanaged Switch features a compact desktop form factor that can be placed on a desk, mounted against a wall, or installed inside standard 19-inch equipment racks using the included mounting brackets. Powered by an internal universal AC power supply (100V to 240V AC), the unit uses fanless natural heat dissipation for quiet, continuous operation in standard commercial indoor spaces.
