Huawei eKitEngine S110-8P2ST Unmanaged PoE+ Switch (Model: S110-8P2ST) is an 8-port Gigabit Power over Ethernet switch engineered to deliver high-capacity power and data for commercial security, VoIP, and Wi-Fi access networks. It features 8 fixed 10/100/1000BASE-T Gigabit Ethernet ports compliant with IEEE 802.3at/af PoE+ providing up to 30W per port with a 124W total PoE budget, 1 dedicated GE SFP optical slot, and 1 Gigabit RJ45 copper uplink, achieving 20 Gbps switching bandwidth and 14.88 Mpps packet forwarding throughput.
Housed in a sturdy metal chassis with fanless natural heat dissipation, the switch delivers plug-and-play simplicity without requiring network configuration. It provides reliable Power over Ethernet for IP surveillance cameras, wireless access points, and VoIP desktop phones.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKitEngine S110 Series |
| Model / SKU | S110-8P2ST |
| Management Type | Unmanaged (Plug-and-Play) |
| Downlink Ports | 8 × 10/100/1000BASE-T Gigabit RJ45 Ports (IEEE 802.3at/af PoE+) |
| PoE Power Budget | 124W Dedicated PoE+ Power Budget (Up to 30W per Port) |
| Uplink Interfaces | 1 × GE SFP Optical Port + 1 × 10/100/1000BASE-T RJ45 Port |
| Switching Bandwidth | 20 Gbit/s Wire-Speed Bandwidth |
| Packet Forwarding Rate | 14.88 Mpps |
| Form Factor | Compact Desktop / 1U Rackmount Compatible Metal Chassis |
| Power Supply | Internal Universal AC Power Supply (100V to 240V AC) |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Desktop / 1U Rackmount Compatible |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Heavy-Gauge Steel Enclosure |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- High-Power 124W PoE+ Budget: 8 Gigabit PoE+ ports deliver up to 30W per port with a 124W total budget, powering high-draw PTZ cameras and Wi-Fi 6 APs.
- Flexible Fiber & Copper Uplinks: 1 dedicated Gigabit SFP optical slot and 1 RJ45 uplink enable long-distance and copper backhauls.
- Wire-Speed Performance: Generates 20 Gbps switching bandwidth and 14.88 Mpps packet forwarding rate with zero packet loss.
- Fanless Quiet Operation: Passive natural heat dissipation ensures noise-free operation in open office spaces and retail shops.
- Plug-and-Play Deployment: Automatic MDI/MDIX crossover and auto-negotiation eliminate complex software setup.
- Internal Universal AC Power: Built-in AC power supply streamlines installation without external power adapters.
Recommended Applications
The Huawei eKitEngine S110-8P2ST Unmanaged PoE+ Switch is engineered for access and aggregation scenarios across commercial environments:
- Powering and connecting up to 8 high-definition IP surveillance cameras for retail stores, warehouses, and offices.
- Supplying PoE+ power to commercial Wi-Fi 6 wireless access points in boutique hotels and clinics.
- Enterprise VoIP telephony deployments powering 8 desktop IP phones without separate electrical outlets.
- Commercial edge aggregation transmitting surveillance video over fiber uplinks to centralized NVR servers.
- Small business workspaces requiring silent, fanless Power over Ethernet distribution.
Installation & Operating Environment
The Huawei eKitEngine S110-8P2ST Unmanaged PoE+ Switch features a heavy-gauge metal chassis supplied with a complete rackmount bracket kit and rubber feet for desktop, wall, or 19-inch rack installations. Powered by an internal universal AC power supply, it maintains efficient natural heat dissipation for continuous, silent operation in enterprise environments.
