Huawei eKitEngine S530-24ST4XE Aggregation Switch (Model: S530-24ST4XE) is an enterprise-class Layer 3 optical switch engineered with 24 Gigabit SFP ports, quad 10G SFP+ uplinks, and dual 10G stacking ports to provide high-density fiber aggregation for campus networks. It features 24 GE SFP ports (8 of which are dual-purpose 10/100/1000BASE-T combo ports), 4 dedicated 10GE SFP+ optical slots, and 2 dedicated 10GE hardware stacking ports, delivering 176 Gbps switching bandwidth and 132 Mpps forwarding throughput.
Housed in a standard 1U 19-inch rackmount metal enclosure with internal power supply, the switch delivers carrier-class routing protocols including OSPF, IS-IS, BGP, RIP, VRRP, PIM, IPv4/IPv6 Dual Stack, and Hardware Stacking. Management is supported via the Huawei eKit Cloud Platform, Web GUI, full CLI via SSH/Console, and SNMP.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKitEngine S530 Series |
| Model / SKU | S530-24ST4XE |
| Optical Downlinks | 24 × GE SFP Ports (8 of which are Dual-Purpose 10/100/1000BASE-T Combo Ports) |
| Uplink Interfaces | 4 × 10GE SFP+ Dedicated High-Speed Optical Slots |
| Dedicated Stacking | 2 × 10GE Dedicated Hardware Stacking Ports |
| Switching Bandwidth | 176 Gbit/s Wire-Speed Non-Blocking Bandwidth |
| Packet Forwarding Rate | 132 Mpps |
| Routing & Layer 3 | OSPF, IS-IS, BGP, RIP, VRRP, PIM, IPv4/IPv6 Dual Stack, Hardware Stacking |
| Management Capabilities | Huawei eKit Cloud Platform, Web GUI, Full CLI via SSH/Console, SNMP v1/v2c/v3 |
| Form Factor | Standard 1U 19-Inch Rackmount Metal Enclosure with Internal Power Supply |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Standard 1U 19-Inch Rackmount Enclosure |
| Heat Dissipation Mode | Smart Thermal Heat Dissipation |
| Acoustic Profile | Controlled Commercial Acoustic Profile |
| Chassis Construction | Heavy-Duty Steel Enclosure |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- High-Density Optical Aggregation: 24 GE SFP optical ports aggregate distributed campus edge switches over fiber.
- Dedicated 10G Hardware Stacking: Dual 10GE stack ports enable single-IP management and sub-second failover across stacked switches.
- Quad 10G SFP+ Optical Uplinks: 4 dedicated 10GE SFP+ optical slots deliver high-capacity backhaul to core datacenter networks.
- Dynamic Routing Suite: Full enterprise dynamic routing support including OSPF, IS-IS, BGP, RIP, and multicast PIM.
- High Reliability Architecture: Hardware stacking and VRRP router redundancy deliver high availability for continuous operations.
- Standard 1U Metal Chassis: 19-inch metal enclosure includes complete rackmount brackets, screws, and rubber feet.
Recommended Applications
The Huawei eKitEngine S530-24ST4XE Aggregation Switch is engineered for access and aggregation scenarios across commercial environments:
- Consolidating 24 remote edge switches over single-mode or multimode fiber across university and corporate campuses.
- Creating high-resilience virtual chassis clusters using dual 10G stacking ports with unified single-IP management.
- Serving as enterprise core and distribution switches with dynamic OSPF and BGP routing acceleration.
- Providing VRRP redundancy and high reliability for 24/7 mission-critical commercial LAN operations.
- Supplying high-density optical aggregation across smart city infrastructure and metropolitan distribution hubs.
Installation & Operating Environment
The Huawei eKitEngine S530-24ST4XE Aggregation Switch features a standard 1U 19-inch rackmount metal chassis supplied with heavy-duty mounting brackets and rubber feet for immediate rack installation. Powered by an internal universal AC power supply, it maintains efficient thermal dissipation and continuous operational uptime in enterprise facilities.
