Huawei eKitEngine S110-24T2SR Unmanaged Gigabit Switch (Model: S110-24T2SR) is a high-density 24-port Gigabit Ethernet switch engineered to deliver configuration-free, wire-speed connectivity for enterprise commercial networks. It features 24 fixed 10/100/1000BASE-T RJ45 Gigabit ports and 2 dedicated GE SFP optical transceiver slots, delivering an aggregate switching bandwidth of 52 Gbps and a packet forwarding throughput of 38.69 Mpps.
Housed in a standard 1U 19-inch rackmount metal enclosure with internal universal AC power, the switch operates with fanless natural heat dissipation. Designed for plug-and-play commercial deployments, it provides silent operation for noise-sensitive business environments.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKitEngine S110 Series |
| Model / SKU | S110-24T2SR |
| Management Type | Unmanaged (Plug-and-Play) |
| Downlink Ports | 24 × 10/100/1000BASE-T Gigabit RJ45 Ports |
| Uplink Interfaces | 2 × GE SFP Optical Transceiver Slots |
| Switching Bandwidth | 52 Gbit/s Wire-Speed Bandwidth |
| Packet Forwarding Rate | 38.69 Mpps |
| MAC Address Table | Up to 8K MAC Address Entries |
| Form Factor | Standard 1U 19-Inch Rackmount Metal Chassis |
| Power Supply | Internal Universal AC Power Supply (100V to 240V AC) |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Standard 1U 19-Inch Rackmount Chassis |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Heavy-Duty Industrial Steel Enclosure |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- High Port Density: 24 Gigabit Ethernet ports provide 52 Gbps switching bandwidth and 38.69 Mpps forwarding throughput for corporate workgroups.
- Dedicated Dual SFP Fiber Uplinks: 2 Gigabit SFP optical slots enable long-distance fiber connections to core switches.
- Fanless Quiet Operation: Passive natural heat dissipation ensures noise-free operation in open office spaces and retail shops.
- Plug-and-Play Simplicity: Unmanaged design requires zero configuration, providing instant network expansion upon connection.
- Internal Universal AC Power: Integrated internal power supply simplifies cabinet cable management.
- Standard 1U Rack Chassis: Heavy-duty 19-inch metal enclosure includes complete rackmount brackets, screws, and rubber feet.
Recommended Applications
The Huawei eKitEngine S110-24T2SR Unmanaged Switch is engineered for access and aggregation scenarios across commercial environments:
- High-density corporate office workgroups connecting up to 24 employee workstations and network printers.
- Hotel guest rooms and administrative offices requiring high port count with silent, fanless operation.
- School computer labs and educational classrooms providing reliable high-speed wired access.
- Commercial retail outlets and department stores linking point-of-sale terminals and back-office PCs.
- Branch office edge distribution providing fiber uplinks back to enterprise core switches.
Installation & Operating Environment
The Huawei eKitEngine S110-24T2SR Unmanaged Switch features a standard 1U 19-inch metal chassis supplied with a complete rackmount bracket kit and rubber feet for seamless installation in commercial server racks or on desktops. Powered by an internal universal AC power supply, it maintains efficient natural heat dissipation for continuous, quiet operation in enterprise facilities.
