Huawei eKitEngine S220S-8T2X / S310S-8T2X Layer 2 Managed Switch (Model: S220S-8T2X) is an enterprise access switch engineered with dual 10-Gigabit SFP+ optical uplinks to deliver high-bandwidth connectivity for commercial networks. It features 8 fixed 10/100/1000BASE-T Gigabit Ethernet ports and 2 dedicated 10GE SFP+ optical transceiver slots, achieving a switching bandwidth of 56 Gbps and a packet forwarding rate of 42 Mpps.
Housed in a standard 1U 19-inch rackmount metal chassis with internal universal AC power and fanless natural heat dissipation, the switch delivers enterprise Layer 2 features including 802.1Q VLANs, Link Aggregation (LACP), STP/RSTP/MSTP, IGMP Snooping, and ACLs with full cloud management via Huawei eKit.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKitEngine S220S / S310S Series |
| Model / SKU | S220S-8T2X (S310S-8T2X) |
| Downlink Ports | 8 × 10/100/1000BASE-T Gigabit Ethernet Ports |
| Uplink Interfaces | 2 × 10GE SFP+ Dedicated High-Speed Optical Slots |
| Switching Bandwidth | 56 Gbit/s Wire-Speed Bandwidth |
| Forwarding Rate | 42 Mpps |
| Layer 2 Capabilities | 802.1Q VLANs, Link Aggregation (LACP), STP/RSTP/MSTP, IGMP Snooping, ACLs |
| Management Architecture | Huawei eKit Cloud Platform, Web GUI, Full CLI via SSH/Console, SNMP |
| Form Factor | Standard 1U Rackmount / Desktop Enclosure |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Standard 1U 19-Inch Rackmount Chassis |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Heavy-Gauge Industrial Steel Housing |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- Dual 10G SFP+ Optical Uplinks: 2 dedicated 10GE SFP+ optical slots eliminate network bottlenecks connecting to core switches.
- Wire-Speed Performance: Generates 56 Gbps switching bandwidth and 42 Mpps forwarding rate for high-concurrency client environments.
- Fanless Quiet Operation: Passive natural heat dissipation ensures noise-free operation in open office spaces and retail shops.
- Layer 2 Management Suite: Full support for 802.1Q VLANs, LACP port trunking, spanning tree protocols, and IGMP snooping.
- Cloud & App Management: Remote network monitoring, topology visualization, and port management via Huawei eKit App.
- Standard 1U Rack Chassis: Heavy-duty 19-inch metal enclosure includes complete rackmount brackets, screws, and rubber feet.
Recommended Applications
The Huawei eKitEngine S220S-8T2X Managed Switch is engineered for access and aggregation scenarios across commercial environments:
- 10G Core Uplinks: Eliminating network bottlenecks with 10G optical fiber uplinks to core switches.
- Enterprise Branch Access: Secure, policy-driven Layer 2 network switching with enterprise ACLs.
- CAD & Media Workgroups: High-throughput data transfers for designers, engineers, and local servers.
- Cloud-Managed Workspaces: Centralized provisioning and automated maintenance via Huawei eKit.
- Hospitality and healthcare clinics requiring silent, fanless 10G edge switching.
Installation & Operating Environment
The Huawei eKitEngine S220S-8T2X Managed Switch features a standard 1U 19-inch metal chassis supplied with mounting brackets and rubber feet for seamless installation in commercial server racks or on desktops. Powered by an internal universal AC power supply, it maintains efficient natural heat dissipation for continuous, quiet operation in enterprise facilities.
