Huawei eKit S220S-8T2J Managed Gigabit Switch (Model: S220S-8T2J) is an enterprise Layer 2+ switch engineered with 2.5G optical uplinks to provide high-speed, cloud-managed edge distribution for commercial workspaces. It features 8 fixed 10/100/1000BASE-T Gigabit RJ45 ports and 2 dedicated 2.5GE SFP optical transceiver slots, delivering an aggregate switching bandwidth of 26 Gbps and a packet forwarding rate of 19 Mpps.
Housed in a compact metal chassis with fanless natural heat dissipation and internal AC power, the switch delivers enterprise Layer 2+ features including Static Routing, 802.1Q VLANs, Link Aggregation (LACP), and Port Isolation with full cloud management via Huawei eKit.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKit S220S Series |
| Model / SKU | S220S-8T2J |
| Management Interface | Huawei eKit Cloud Platform, Mobile App, Web GUI, Full CLI |
| Downlink Ports | 8 × 10/100/1000BASE-T Gigabit RJ45 Ports |
| Uplink Interfaces | 2 × 2.5GE SFP High-Speed Optical Transceiver Slots |
| Switching Bandwidth | 26 Gbit/s Wire-Speed Bandwidth |
| Packet Forwarding Rate | 19 Mpps |
| Layer 2+ Features | Static Routing, 802.1Q VLANs, LACP Link Aggregation, Port Isolation |
| Form Factor | Compact Desktop / Rackmount Metal Chassis with Internal AC Power |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Compact Desktop / 1U Rackmount Compatible |
| Heat Dissipation Mode | Fanless, Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Industrial-Grade Steel Housing |
| Power Supply | Internal Universal AC Power Supply |
Key Features & Highlights
- High-Speed 2.5G SFP Uplinks: 2 dedicated 2.5GE SFP optical slots deliver high-capacity backhaul to core distribution switches.
- Wire-Speed Performance: Generates 26 Gbps switching bandwidth and 19 Mpps forwarding rate for smooth business operations.
- Fanless Quiet Operation: Passive natural heat dissipation ensures noise-free operation in open office spaces and retail shops.
- Layer 2+ Static Routing: Hardware-based IPv4 static routing simplifies traffic flow between departmental subnets.
- Cloud & App Management: Remote network monitoring, topology visualization, and port management via Huawei eKit App.
- Heavy-Duty Metal Enclosure: Industrial-grade metal housing ensures electromagnetic shielding and durability.
Recommended Applications
The Huawei eKit S220S-8T2J Managed Gigabit Switch is engineered for access and aggregation scenarios across commercial environments:
- Small business office workgroups connecting up to 8 desktop workstations, network printers, and NAS devices.
- Connecting high-throughput edge nodes to core network infrastructure over dual 2.5G SFP optical uplinks.
- Cloud-managed multi-branch IT deployments requiring zero-touch remote provisioning via the Huawei eKit App.
- Hospitality guest service areas and reception desks needing silent, fanless operation without disturbing visitors.
- Noise-sensitive business workspaces requiring high-performance edge switching without dedicated server rooms.
Installation & Operating Environment
The Huawei eKit S220S-8T2J Managed Gigabit Switch features a compact desktop form factor that can be placed on a desk, mounted against a wall, or installed inside standard 19-inch equipment racks using the included mounting brackets. Powered by an internal universal AC power supply, it maintains efficient natural heat dissipation for continuous, quiet operation in enterprise facilities.
