Cable Parameter
- Fiber Count: 48Core
- Colored Coating Fiber :
Dimension: 250μm±15μm
Color: Blue, Orange, Green, Brown, Gray, White, Red, Black, Yellow, Purple, Pink, Aqua blue
- Loose Tube:
Dimension: 2.8mm±0.1mm
Material: PBT
Tube Color: Blue, orange, green, brown
Loose tube number: 4
Filling rope number: 1
The fiber in loose tube number: 12
- Material of reinforcement: Phosphating steel wire 1.0mm
- Outer / Inner Jacket :
Diameter: I1.6mm±0.10mm
Material: HDPE
Sheath color: Black
Line color: Yellow
- Sheath outer diameter: 10mm±0.2mm
