Huawei eKITEngine AP362 Wi-Fi 6 Access Point (Model: AP362) is a high-performance ceiling wireless access point engineered with 2.975 Gbps throughput, smart antennas, and 256-user capacity for medium-density commercial venues. It supports dual-radio Wi-Fi 6 (IEEE 802.11ax) operation across 2.4 GHz and 5 GHz concurrent frequencies with integrated smart antennas providing an 18-meter optimal coverage radius and 20 dBm transmit power.
Housed in a ceiling-mount and wall-mount circular metal and polycarbonate enclosure, the access point is powered via PoE (IEEE 802.3af/at) or 12V DC external power. It integrates with the Huawei eKit Cloud Platform, Leader AP architecture, and hardware AC controllers for flexible multi-site management.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKITEngine Series |
| Model / SKU | Huawei eKITEngine AP362 |
| Wi-Fi Standard | Wi-Fi 6 (IEEE 802.11ax) Dual-Radio (2.4 GHz & 5 GHz Concurrent) |
| Maximum Wireless Speed | Up to 2.975 Gbps Aggregate Wireless Throughput |
| Antenna Technology | Integrated Smart Antennas with 18-Meter Optimal Coverage Radius |
| Transmit Power | 20 dBm Transmit Power |
| User Capacity | Recommended: 80 Concurrent Users | Maximum: 256 Access Users |
| Power Supply | PoE (IEEE 802.3af/at) or 12V DC External Input |
| Management Capabilities | Huawei eKit Cloud Platform, Leader AP Architecture, AC Controller |
| Form Factor | Ceiling-Mount / Wall-Mount Circular Metal & Polycarbonate Enclosure |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Ceiling-Mount / Wall-Mount Circular Enclosure |
| Heat Dissipation Mode | Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | Metal Base with Commercial Polycarbonate Cover |
| Power Options | PoE 802.3af/at or 12V DC Input |
Key Features & Highlights
- High-Speed 2.975 Gbps Throughput: Dual-radio Wi-Fi 6 delivers high data rates for bandwidth-intensive commercial applications.
- 256 Maximum User Capacity: High-concurrency architecture supports 80 recommended and up to 256 total access devices.
- Smart Antenna Array: Integrated beamforming antennas provide consistent 18-meter coverage across open-plan offices.
- Dual Power Flexibility: Operates via standard PoE (802.3af/at) or external 12V DC power input.
- Leader AP Controllerless Clustering: Automatic AP group management and coordination without separate hardware AC.
- Cloud Platform Integration: Mass configuration, RF power calibration, and remote health diagnostics via Huawei eKit.
Recommended Applications
The Huawei eKITEngine AP362 Wi-Fi 6 Access Point is engineered for access and aggregation scenarios across commercial environments:
- Medium-density corporate office floors connecting up to 256 client devices with fast 2.975 Gbps bandwidth.
- Conference rooms and auditoriums requiring smart beamforming to ensure low latency during multi-stream video calls.
- Healthcare clinics and hospital wards providing reliable roaming for mobile medical tablets and equipment carts.
- Education lecture halls delivering high-concurrency access for students using laptops and tablets simultaneously.
- Commercial showrooms and hospitality lobbies handling high volumes of visitor wireless traffic.
Installation & Operating Environment
The Huawei eKITEngine AP362 Wi-Fi 6 Access Point features a ceiling and wall mountable circular enclosure supplied with a ceiling rail and wall mounting bracket kit with screws. Powered by PoE (IEEE 802.3af/at) or 12V DC, it utilizes natural heat dissipation for quiet, continuous operation in commercial indoor environments.
