Huawei eKITEngine AP362E Enhanced Wi-Fi 6 Access Point (Model: AP362E) is an enterprise ceiling access point engineered with high 23 dBm transmit power, smart antennas, and a 20-meter coverage radius to deliver robust wireless connectivity across commercial spaces. It delivers up to 2.975 Gbps maximum throughput across concurrent 2.4 GHz and 5 GHz frequencies with high-power RF output.
Housed in an aesthetically pleasing ceiling and wall mountable enclosure, the access point is powered via PoE (IEEE 802.3af/at) or 12V DC external power. It supports 100 recommended concurrent users (up to 128 access users) with management through the Huawei eKit Cloud Platform, Leader AP architecture, and hardware AC controllers.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKITEngine Series |
| Model / SKU | Huawei eKITEngine AP362E |
| Wi-Fi Standard | Wi-Fi 6 (IEEE 802.11ax) Dual-Radio (2.4 GHz & 5 GHz Concurrent) |
| Aggregate Wireless Speed | Up to 2.975 Gbps Maximum Throughput |
| Transmit Power | 23 dBm High-Power RF Output |
| Antenna & Coverage | Smart Antenna Array with 20-Meter Optimal Coverage Radius |
| User Capacity | Recommended: 100 Concurrent Users | Maximum: 128 Access Users |
| Power Supply | PoE (IEEE 802.3af/at) or 12V DC External Input |
| Management Interface | Huawei eKit Cloud Platform, Leader AP Architecture, AC Controller |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Ceiling-Mount / Wall-Mount Low-Profile Enclosure |
| Heat Dissipation Mode | Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | High-Durability Commercial Polymer Housing |
| Power Input Modes | PoE 802.3af/at or 12V DC External Power |
Key Features & Highlights
- Enhanced 23 dBm RF Power: High-power output and smart antennas deliver expansive 20-meter coverage across large commercial floors.
- 2.975 Gbps Wi-Fi 6 Speeds: Dual-band concurrent operation ensures fast data transfer for high-bandwidth applications.
- 100-User Recommended Capacity: Supports 100 recommended active users and up to 128 total access users without congestion.
- Smart Antenna Array: Integrated beamforming antennas dynamically direct signal toward connected clients for reliable connectivity.
- Flexible Power Architecture: Powered via PoE (802.3af/at) over Ethernet cabling or standard 12V DC adapter.
- Cloud & Leader AP Modes: Zero-touch Leader AP controllerless clustering or centralized Huawei eKit cloud management.
Recommended Applications
The Huawei eKITEngine AP362E Enhanced Wi-Fi 6 Access Point is engineered for access and aggregation scenarios across commercial environments:
- High-ceiling commercial buildings utilizing 23 dBm high power and 20m range covering expansive commercial floors.
- Open-plan enterprise offices supporting 100 recommended users with steady, high-speed Wi-Fi 6 bandwidth.
- Exhibition halls and art galleries requiring wide-area coverage to minimize the total number of deployed APs.
- Hospitality lobbies and restaurants providing seamless guest roaming and captive portal authentication.
- Educational seminar rooms and lecture halls requiring strong signal penetration through walls and partitions.
Installation & Operating Environment
The Huawei eKITEngine AP362E Enhanced Wi-Fi 6 Access Point features a low-profile ceiling and wall mountable chassis supplied with a ceiling grid and wall mounting bracket kit with screws. Powered by PoE (IEEE 802.3af/at) or 12V DC, it utilizes natural heat dissipation for quiet, continuous operation in commercial facilities.
