Huawei eKITEngine AP371 Wi-Fi 7 Access Point (Model: AP371) is a cutting-edge enterprise access point engineered with Wi-Fi 7 technology, 3.57 Gbps wireless speed, and smart antennas to deliver ultra-high throughput and minimal latency for modern work environments. It features dual-radio IEEE 802.11be architecture supporting Multi-Link Operation (MLO), 4096-QAM modulation, and Multi-RU puncturing with an 18-meter optimal coverage radius and 23 dBm transmit power.
Housed in a low-profile ceiling and wall mountable enclosure, the access point is powered via PoE (IEEE 802.3at/af) or 12V DC external power. It supports 150 recommended concurrent users (up to 256 access users) with management via the Huawei eKit Cloud Platform, Leader AP, and hardware AC controllers.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei eKITEngine Series |
| Model / SKU | Huawei eKITEngine AP371 |
| Wi-Fi Standard | Next-Gen Wi-Fi 7 (IEEE 802.11be) Dual-Radio Architecture |
| Maximum Wireless Speed | Up to 3.57 Gbps Aggregate Data Rate (Multi-Link Operation MLO Supported) |
| Antenna & Coverage | Integrated Smart Antennas with 18-Meter Optimal Coverage Radius |
| Transmit Power | 23 dBm Transmit Power |
| User Concurrency | Recommended: 150 Concurrent Users | Maximum: 256 Access Users |
| Wi-Fi 7 Innovations | 4096-QAM Modulation, Multi-Link Operation (MLO), Multi-RU Puncturing |
| Power Architecture | PoE (IEEE 802.3at/af) or 12V DC External Power |
| Management Architecture | Huawei eKit Cloud Platform, Leader AP, Hardware AC Management |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Ceiling / Wall Mount Low-Profile Circular Chassis |
| Heat Dissipation Mode | Natural Heat Dissipation |
| Acoustic Profile | Noise-Free Operation |
| Chassis Construction | High-Performance Polymer and Metal Enclosure |
| Power Input | PoE (802.3at/af) or 12V DC External Input |
Key Features & Highlights
- Next-Gen Wi-Fi 7 Speed: Aggregate throughput up to 3.57 Gbps delivers multi-gigabit wireless performance for modern enterprises.
- Multi-Link Operation (MLO): Simultaneously transmits data across 2.4 GHz and 5 GHz bands to minimize latency and eliminate packet jitter.
- 4096-QAM High-Density Modulation: Increases data transmission density by 20% compared to Wi-Fi 6 for maximum spectral efficiency.
- Multi-RU Puncturing: Intelligently avoids channel interference and utilizes fragmented spectrum for higher throughput.
- 150+ Concurrent Users: Supports 150 recommended active users and up to 256 total access users with zero network lag.
- Integrated Smart Antennas: Beamforming smart antennas provide steady 18-meter coverage across commercial workspaces.
Recommended Applications
The Huawei eKITEngine AP371 Wi-Fi 7 Access Point is engineered for access and aggregation scenarios across commercial environments:
- Next-generation Wi-Fi 7 workplaces utilizing 3.57 Gbps speeds and MLO to eliminate latency for AR/VR and 4K conferencing.
- High-density enterprise offices supporting 150+ concurrent users with 4096-QAM high-density modulation.
- Financial trading floors and telehealth consult rooms requiring ultra-low jitter and sub-millisecond latency.
- Future-proof enterprise network upgrades providing turnkey transition to IEEE 802.11be Wi-Fi 7 standards.
- High-tech design studios and university computer labs requiring high-throughput wireless data transfers.
Installation & Operating Environment
The Huawei eKITEngine AP371 Wi-Fi 7 Access Point features a low-profile circular chassis supplied with a ceiling rail and wall mount bracket kit with screws. Powered via PoE (IEEE 802.3at/af) or 12V DC, it maintains natural heat dissipation for quiet, continuous operation in commercial work environments.
