Huawei IdeaHub OPS i5 Windows 10 IoT PC Module (Model: ICD OPS i5 D) is a slide-in modular Open Pluggable Specification (OPS) computer engineered with an Intel Core i5 6-core processor, 8GB DDR4 memory, and a 128GB SSD to deliver seamless dual-OS Windows functionality for IdeaHub interactive displays. It features Windows 10 IoT Enterprise SAC, Intel UHD Graphics 630 with 4K UHD 60Hz output, and an 80-pin JAE interface connector.
Sliding directly into the rear expansion bay of IdeaHub displays, it turns the screen into a dual-system powerhouse, enabling instant one-touch switching between HarmonyOS whiteboarding and native Windows desktop. It includes Gigabit Ethernet, USB 3.0, and HDMI 2.0 output.
Technical Specifications
| Component / Parameter | Technical Specification |
|---|---|
| Product Line | Huawei IdeaHub Modular Computing |
| Model / SKU | ICD OPS i5 D |
| Processor (CPU) | Intel Core i5-10500 Processor (6 Cores, 12 Threads, Up to 4.50 GHz Turbo) |
| System Memory (RAM) | 8 GB DDR4 High-Speed RAM (Expandable) |
| Storage Capacity | 128 GB M.2 NVMe Solid-State Drive (SSD) |
| Operating System | Windows 10 IoT Enterprise SAC Pre-Installed and Licensed |
| Hardware Interface | Standard 80-Pin JAE Open Pluggable Specification (OPS) Interface |
| Graphics Output | Intel UHD Graphics 630 Supporting Native 4K UHD @ 60Hz Output |
| I/O Connectivity | USB 3.0 Ports, HDMI Output, Gigabit RJ45 LAN Port, 3.5mm Audio Out |
Mechanical & Environmental Specifications
| Parameter / Feature | Specification / Rating |
|---|---|
| Form Factor | Standard OPS Slide-In Module (195mm × 180mm × 30mm) |
| Heat Dissipation Mode | Internal Quiet Blower Heat Dissipation |
| Acoustic Profile | Low-Noise Operation |
| Chassis Construction | High-Strength Aluminum Enclosure |
| Power Input | Direct DC Power from Display Host OPS Slot |
Key Features & Highlights
- Intel Core i5 6-Core Performance: Delivers fast processing power for enterprise productivity, CAD viewers, and Office 365.
- Seamless Slide-In Architecture: 80-pin JAE OPS connector provides instant toolless installation without external power cords.
- Pre-Activated Windows 10 IoT: Enterprise-grade OS provides long-term stability and compatibility with corporate software.
- One-Touch Dual OS Switching: Switch instantly between HarmonyOS whiteboarding and Windows workspace on screen.
- 4K UHD 60Hz Graphics: Intel UHD Graphics 630 drives ultra-crisp 4K video rendering and dynamic presentations.
- Complete I/O Array: USB 3.0, HDMI, Gigabit Ethernet, and Wi-Fi antennas expand peripheral connectivity.
Recommended Applications
The Huawei IdeaHub Modular OPS i5 Windows PC Module is engineered for access and aggregation scenarios across commercial environments:
- Running native Windows conference software including Microsoft Teams Rooms, Zoom Rooms, and Webex.
- Displaying and manipulating complex Microsoft Office 365 spreadsheets, presentations, and PowerBI dashboards.
- Interactive classroom teaching running Windows-native educational courseware and simulation tools.
- Enabling corporate enterprise Active Directory domain join and Windows security policy enforcement.
- Transforming IdeaHub displays into standalone Windows workstations with full touch screen interactivity.
Installation & Operating Environment
The Huawei IdeaHub Modular OPS i5 Windows PC Module slides directly into the dedicated rear OPS slot of Huawei IdeaHub displays and fastens securely with two captive thumb screws. Power and display connections are routed internally through the 80-pin JAE connector, eliminating external power supplies and video cables.
